Belparts excavator main pump R140LC-7 R140LC-7A R140LC-9 hydraulic pump 31Q4-10010 31N3-10010 31N3-10011

  • 1
  • 2
  • 3

Brand Name : Belparts

Model Number : R140LC-7 R140LC-7A R140LC-9

Place of Origin : Made in china

MOQ : 1PCS

Price : Negotiated price

Payment Terms : T/T, trade assurance,PayPal

Supply Ability : 1000PCS

Delivery Time : 1~7 days

Packaging Details : Wooden case

Model : R140LC-7 R140LC-7A R140LC-9

part number : 31Q4-10010 31N3-10010 31N3-10011

Warranty : 1 Year

Texture : Steel

Part name : Hydraulic pump

Contact Now

Belparts excavator main pump R140LC-7 R140LC-7A R140LC-9 hydraulic pump 31Q4-10010 31N3-10010 31N3-10011


Appliion:Crawler excavator
Part name:Hydraulic Main Pump
Model:R140LC-7 R140LC-7A R140LC-9
Part number:31Q4-10010 31N3-10010 31N3-10011
Warranty:3-12 months
Payment term:T/T, Trade Assurance, Paypal and etc.
Brand:Hitachi or as require

Appliion Crawler excavator
Part name Hydraulic Main Pump
Model R140LC-7 R140LC-7A R140LC-9
Part number 31Q4-10010 31N3-10010 31N3-10011
Warranty 3-12 months
Payment term T/T, Trade Assurance, Paypal and etc.
Brand Hitachi or as require



# Part No Part Name Qty. Price request
* 31N3-10010 MAIN PUMP 1  
* 31N3-10011 MAIN PUMP 1  
111 XJBN-00432 SHAFT(F)-DRIVE 1  
113 XJBN-00431 SHAFT(R)-DRIVE 1  
114 XJBN-00430 COUPLING-SPLINE 1  
123 XJBN-00429 BEARING-ROLLER 2  
124 XJBN-00428 BEARING-NEEDLE 2  
127 XJBN-00427 SPACER-BEARING 4  
N141 XJBN-00426 BLOCK-CYLINDER 2  
N151 XJBN-00425 PISTON 18  
N152 XJBN-00424 SHOE 18  
153 XJBN-00423 PLATE-SET 2  
156 XJBN-00422 BUSHING-SPHERICAL 2  
157 XJBN-00421 SPRING-CYLINDER 18  
211 XJBN-00420 PLATE-SHOE 2  
N212 XJBN-00419 PLATE-SWASH 2  
N214 XJBN-00418 BUSHING-TILTING 2  
251 XJBN-00417 SUPPORT 2  
261 XJBN-00416 COVER(F)-SEAL 1  
271 XJBN-00415 CASING-PUMP 2  
312 XJBN-00414 BLOCK-VALVE 1  
N313 XJBN-00413 PLATE(R)-VALVE 1  
N314 XJBN-00412 PLATE(L)-VALVE 1  
401 XJBN-00411 SCREW 8  
406 XJBN-00410 SCREW 4  
466 XJBN-00356 PLUG 2  
467 XJBN-00409 PLUG 4  
490 XJBN-00032 PLUG 15  
N531 XJBN-00408 PIN-TILTING 2  
532 XJBN-00407 PISTON-SERVO 2  
534 XJBN-00406 STOPPER(L) 2  
535 XJBN-00405 STOPPER(S) 2  
N548 XJBN-00404 PIN-FEED BACK 2  
702 XJBN-00232 O-RING 2  
702 XJBN-00817 O-RING 2  
710 XJBN-00387 O-RING 1  
717 XJBN-00401 O-RING 2  
719 XJBN-00400 O-RING 2  
724 XJBN-00044 O-RING 18  
725 XJBN-00045 O-RING 2  
728 XJBN-00097 O-RING 4  
732 XJBN-00283 O-RING 2  
732 XJBN-00820 O-RING 2  
774 XJBN-00399 SEAL-OIL 1  
789 XJBN-00398 RING-BACK UP 2  
792 XJBN-00397 RING-BACK UP 2  
808 XJBN-00396 NUT-HEX 4  
824 XJBN-00395 RING-SNAP 2  
885 XJBN-00394 PIN-VALVE PLATE 2  
886 XJBN-00365 PIN-SPRING 4  
901 XJBN-00393 BOLT-EYE 2  
953 XJBN-00105 SCREW-SET 2  
954 XJBN-00392 SCREW-SET 2  
981 XJBN-00391 NAME PLATE 1  
981 XJBN-00156 NAME PLATE 1  
983 XJBN-00341 PIN 2  
011 XJBN-00437 PISTON SUB ASSY 18  
013 XJBN-00436 CYLINDER ASSY-RH 1  
014 XJBN-00435 CYLINDER ASSY-LH 1  
030 XJBN-00434 SWASH PLATE ASSY 2  
530 XJBN-00433 TILTING PIN ASSY
SEE ILLUST		 2  
N @ FUEL INJECTION PIPE & NOZZLE AR  




Model
Nominal
displacement
(ml/r)		 Pressure(MPa) Speed(r/min)
Volumetric
efficiency
(≥%)		 L1 L Intet Outlet
Weight
(kg)

Rated
Max
Min
Rated
Max
a b D a b D
CBHZA-F23-AFφ* 02
20		 20 25 600 2500 3000 92 60 116 25 26.2 52.4 20 22.2 47.6 4.4
CBHZA-F25-AFφ* 25 61.5 119 4.7
CBHZA-F28.2-AFφ* 28.2 63.5 123 4.9
CBHZA-F30-AFφ* 30 64.5 125 5.1
CBHZA-F32-AFφ* 32 65.5 127 5.3
CBHZA-F36-AFφ* 36 68 132 5.7
CBHZA-F40-AFφ* 40 70.5 137 28 6.1
